JBL HDI-1200P

Active Subwoofer

Condition: New
Warranty: 3 Years
Colour: Walnut
HTFH Cat. No.: EB1137
  • 1,000 Watt RMS Class D amplifier
  • Cast frame, Poly-plas™ cone woofer with 3-inch voice coil
  • Single-band Parametric EQ
  • Low Pass Crossover and Gain controls with selectable Phase switch
  • RCA & XLR line-level input
£2,499.00 Each

Be the first to review this product

Order Before 2.30pm to Get Within 7 Days with FREE shipping (UK only)

JBL
JBL HDI-1200P
JBL HDI-1200P JBL HDI-1200P JBL HDI-1200P

Overview

Designed and engineered in JBL’s world-famous acoustic engineering facility in Northridge, California, the HDI-1200P is the foundation of a complete HDI Series surround system. This powered subwoofer features a 12-inch (300mm) Poly-plas™ cone woofer driven by a 1,000 Watt amplifier for powerful dynamics and incredibly accurate sound reproduction. The subwoofer driver in the HDI-1200P takes advantage of the core JBL transducer DNA found in the HDI woofers, delivering maximum output with significantly reduced distortion. This powerful 12-inch (300mm) driver is based on a cast-aluminum frame that supports a large Symmetrical Field design ceramic motor structure with a vented pole using flared exits. A 3-inch long-throw voice coil drives the high-density Poly-plas™ cone. The entire assembly has been Klippel and FEA optimized to extract maximum performance in system. In combination with the 1,000 Watt amplifier and the bass-reflex tuned enclosure, the HDI-1200P plumbs the depths of low frequencies adding a solid foundation and visceral realism to movies and modern music. The HDI-1200P amplifier offers a choice of RCA or XLR line-level inputs, along with a full complement of controls to tailor the performance for any given room or system configuration. Gain and Low Pass Crossover controls are provided along with a selectable Phase switch and single-band Parametric EQ controls. System integration is managed via selectable Auto Power switch or the 12V Trigger input with pass-thru output. The platform delivers 1,000 Watts RMS with significant peak power output to handle even the largest dynamic demands. Advanced protection and monitoring ensures that the HDI-1200P will continue to deliver optimal performance under less-than-ideal conditions. The HDI-1200P enclosure is heavily braced to provide a solid acoustic foundation, and incorporates a bass reflex design with dual down-firing, computer-optimized flared ports. The sophisticated curved cabinet features a modern design finished in a choice of automotive-grade painted High Gloss Black, or furniture-grade satin Walnut or Gray Oak wood veneers. A black cloth, magnetically attached grille completes the elegant appearance.

Technical Specification

JBL HDI-1200P

Description 1000W powered subwoofer Low Frequency Driver 12" (300mm) black Poly-plas™ cone, cast-frame woofer Recommended Amplifier Power 1000W rms Crossover Frequency 50Hz – 150Hz (variable) 24dB/octave Frequency Response 28Hz – 150Hz (-6dB) Enclosure Type: Bass-reflex design with down-firing ports Power Requirements 100V – 240V 50/60Hz Power Consumption (idle/max) <0.5W (standby) 1180W/7.7A (max-230Vac) 1230W/12.87A (max-120Vac) 1190W/15.97A (max-100Vac) Dimensions (H x W x D) 16.95" x 16.3" x 17.77" (430.5 x 414 x 451.3mm) Net Weight 70.8 lbs (31.79kg)

Warranty
3 Years
Manufacturer
JBL
Model Number
HDI-1200P
Colour
Walnut
Total weight
32kg
Length
451mm
Width
414mm
Height
430mm
Voltage
220v / 240v Only
