The AT-VM95ML, features a Nude Microlinear diamond, not only the Microlinear stylus will permit to double the duration of your stylus. The performance of a line contact stylus, will minimize the “inner groove distortion” as well as providing extended frequency response and maximize resolution in the medium and high frequencies of the audio program material.
Technical Specification
Audio Technica AT-VM95ML/H
Model AT-VM95ML Type VM Stereo Dual Magnet Mounting 1/2” centres Frequency Response 20 - 25,000 Hz Channel Separation 23 dB (1 kHz) Output Channel Balance 1.5 dB (1 kHz) Output Voltage 3.5 mV (@ 1 kHz, 5 cm/sec) Vertical Tracking Angle 23° Vertical Tracking Force Range 1.8 - 2.2g (standard 2.0 g) Stylus Shape Microlinear Stylus Size 2.2 x 0.12 mil Stylus Construction Nude Square Shank Cantilever Aluminium Pipe Coil Impedance 3.3 kΩ (1 kHz) Coil Inductance 550 mH (1 kHz) DC Resistance 485 Ω Static Compliance 20 x 10 – 6 cm / dyne Dynamic Compliance 10 x 10 – 6 cm / dyne (100 Hz) Wire Used for Coil T.P. Copper Recommended Load Impedance 47,000 Ω Recommended Load Capacitance 100-200 pF Cartridge Weight 6.1g Dimensions 17.2 x 18.9 x 28.3 ( H x W x D mm) Replacement Stylus AT-VMN95ML Accessories Included Two 11 mm installation screws; Two 8 mm installation screws; Two washers Non-magnetic screwdriver
