Audio Technica AT-PEQ30

Phono Preamplifier

Condition: New
Warranty: 2 Years
Colour: Silver
HTFH Cat. No.: EB1521
  • Selectable MM and MC input with fixed gain and impedance
  • High-quality FET inputs ensure a low noise signal when incorporated with a negative feedback-type phono equaliser circuit
  • Precision components provide an excellent RIAA response for best-in-class performance
  • All metal construction enclosure provides superior isolation from radio and electronic noise interference
  • Machined aluminium front panel and gold-plated input/output RCA connectors are examples of the high-grade material used throughout
£213.95 Each

Be the first to review this product

Order Before 2.30pm to Get Between 3-5 Working Days Delivery

Audio Technica
Audio Technica AT-PEQ30
Audio Technica AT-PEQ30 Audio Technica AT-PEQ30

Overview

The AT-PEQ30 phono equaliser is designed specifically to upgrade a turntable with a built-in phono amplifier or to add a phono. It is compatible with turntables with VM (dual magnet), MM (moving magnet), and MC (moving coil) cartridges. The PEQ30 benefits from Audio-Technica’s years of analogue audio expertise and uses the finest quality parts in a layout that is optimized for low noise and minimum distortion.

Selectable MM and MC input with fixed gain and impedance allows for compatibility with a wide range of moving magnet and moving coil cartridges
High-quality FET inputs ensure a low noise signal when incorporated with a negative feedback-type phono equalizer circuit
Precision components provide an excellent RIAA response for best-in-class performance
The all metal construction enclosure provides superior isolation from radio and electronic noise interference
The machined aluminium front panel and gold-plated input/output RCA connectors are examples of the high-grade material used throughout

Technical Specification

Audio Technica AT-PEQ30

Input Impedance
MM type: 47 kiloohms
MC type: 120 ohms

Input Sensitivity
MM type: 4.5 mV
MC type: 0.28 mV

Rated Output
MM type: 250 mV
MC type: 250 mV

Gain
MM type: 35 dB
MC type: 59 dB

Signal-to-Noise Ratio
MM type: 100 dB
MC type: 74 dB

RIAA Deviation
(20 to 20,000 Hz) MM type: ±0.5 dB
(20 to 20,000 Hz) MC type: ±0.5 dB

Power Supply
DC 15 V, 1.2 A

Power Consumption
2.5 W

Dimensions
47 mm (1.85") H x
197.5 mm (7.78") W x
125.5 mm (4.94") D
(excluding protrusions)

Weight
About 890 g

Accessories Included
AC adapter

Warranty
2 Years
Manufacturer
Audio Technica
Model Number
AT-PEQ30
Colour
Silver
Weight (Each)
890g
Length (cm)
13
Width (cm)
20
Height (cm)
5
Voltage
220v / 240v Only
